Using this approach, the Report Manager is used to perform all of the BOM layout configuration, such as selecting and arranging the columns, filtering out unneeded rows, including supplier information, and so on. If the project does not include an ActiveBOM, the Report Manager generates the BOM from the project. An ActiveBOM document (BomDoc) - which is the recommended approach.The project - information is extracted from the schematics, as well as connected databases and the PCB, if required.The Report Manager can extract the source information for the BOM from: The Report Manager can generate output in a variety of formats, including PDF, CSV, TXT, Excel, HTML or XML. The final Bill of Materials output is generated by the Report Manager. Creating and managing the BOM through a BomDoc is the recommended approach to BOM Management in Altium Designer. The BomDoc gives instant visibility into the component supply chain and also supports user-defined rows and columns, ideal for including those extra items, such as glue, labels, and so on. The final BOM is generated through a dedicated and powerful report generation engine, the interface to which is known as the Report Manager.įor complete control over the BOM configuration process, including an interactive view of supply chain information as well as custom BOM rows and columns, add an ActiveBOM document (BomDoc) to your project. It also provides a means to calculate cost based on the required number of assembled boards in a requested spin. This report-type document provides a listing of all components required to build the product, including the bare board, which is essentially the base 'component' upon which all other parts are assembled. The BOM acts as a guide for what needs to be procured to build the product as designed. The Bill of Materials, or BOM, is a key ingredient of the data set generated from a board design project. Publishing to PDF Based on an Excel Template.Mapping Document and Project Parameters.Mapping Project-Level, BOM Header Information.Variant Support when the Source is a BomDoc.Using Cached Pricing Data in BOM Parameters when Offline.Including Additional Information Directly to the BOM.Configuring the Layout of the BOM Items.Component Grouping - When the Project is the Source.Component Grouping - When the BomDoc is the Source.
